Great for controlling cylinders and pneumatic actuators.This valve has opened centers. IP65 weatherproof coil an LED DIN plug. Threads conform to ISO 7.1 Sealing Threads.

Model Port Size (BSP) Orifice ømm CV Pressure Media Temperature Weight Kg Coil Specifications
A612-2-7-*NM 1/4 7 2 1.5 to 8 Bar 5°C to 80°C 0.35 SC-A1
5 Watts / 6 Volt Amps
Class H Insulation
100% ED
A612-4-8-*NM 1/2 8 2.8 1.5 to 8 Bar 5°C to 80°C 0.6

*Voltages available; 12vDC, 24vDC, 24vAC, 110vAC, 240vAC, 415vAC

5/3 way solenoid valve closed centres dimensions

Model G(BSP) A B C D E F G H Inlet & Outlet Ports Exhaust Ports K L M
A612-1-5-1N 1/8" 38 17 3.3 20 196 20 4.3 35 1/8" 1/8" 22 36 68
A612-2-7-1N 1/4" 38 17 3.3 20 196 20 4.3 35 1/4" 1/4" 22 36 68
A612-3-7-1N 3/8" 50 20 4.3 24 215 24 4.3 40 3/8" 1/4" 27 45 70
A612-4-8-1N 1/2" 72 27 4.3 36 247 28 5.5 50 1/2" 1/2" 34 63 74

All dimensions in mm unless shown otherwise.

Size 1/4" to 1/2" BSP
Function 5 way 3 position (open centres) double solenoid with manual override
Valve Operation Servo Assisted
Body Aluminium
Seat NBR
Pressure Range 1.5 to 8 BAR
Media Air
