Model d L H1 H Weight (kg)
OB-30-04 1/2" 75 130 318.5 2.7
OB-30-05 3/4" 80 130 318.5 2.8
OB-30-06 1" 90 130 318.5 3

Item Description Material
1 Body Bronze
2 Spring Chamber Bronze
3 Disc PTFE
4 Valve Brass
5 Valve Seat Stainless Steel
6 Balance Bellows Phosphor Bronze
7 Spindle Stainless Steel
8 Collar Brass
9 Nut Brass
10 & 11 Guide Brass
12 Spring Alloy Steel
13 Spring Plate Cast Iron
14 Spring Plate Brass
Item Description Material
15 Adjusting Screw Carbon Steel
16 Washer Stainless Steel
17 Handle Resin
18 Screw Steel
19 Washer Steel
20 Bellows Follower Brass
21 Bellows Phosphor Bronze
22 Ring Brass
23 Gasket PTFE
24 Cap Resin
25 Bolt Carbon Steel
26, 27 & 28 Name Plate Stainless Steel
29 Label Polyester



Size 1/2" to 1" BSPT
Body Broze
Pressure Range 0 to 10 BAR
Temperature Various
